Description
AFV-566 / TV-564
This folder is a highly automated and dynamic machine that achieves new levels of production efficiency in folding. Advanced automation reduces setup time and allows easy operation via color touchscreen. The uniquely designed buckle plate ensures consistent, accurate folds, and accommodates a wider range of substrates. Optional dynamic folding is available to change fold patterns on the fly for variable signatures with no blank sheets in the set. The system also features automatic scoring navigation and double-sheet detection, improved registration, and easier sheet loading.
Key Features
- Automatic Setup – Icon based touchscreen enables intuitive setup and operation.
- Advanced automation – Increased automation and faster automated settings reduces setup time for accurate folding quality with quicker turn around.
- High Quality and Productivity – Uniquely designed buckle plate and folding mechanisms ensures consistent accuracy of folding quality and durability.
- Flexible – Selection of buckle plate and fold roller composition are available to meet a wider variety of folding needs.
MANAGE YOUR BINDERY WITH HORIZON’S BINDERY CONTROL SYSTEM – The system can be enhanced with automated workflow from upstream to post-press with iCE LiNK, which uses cloud technology, Horizon’s post-press management system.
Specifications
| Machine Structure | First Station: AFV-566DF (6 buckle plates / Full Auto / Dynamic Fold) Second Station: TV-564F (4 buckle plates / Full Auto) |
| Sheet Size (Width x Length) | Max. 560 mmx 900 mm/ 22.05” x 35.43” Min. 105* mmx 148 mm/ 4.13” x 5.83” (*Optional guide is required) |
| Belt Speed | 30 to 270 m per minute |
