The trimmer operates in-line with Horizon perfect binders or off-line to deliver a wide range of input and output sizes for completely variable production! Setup and variable trimming are achieved automatically by reading a barcode printed on the cover sheet of each book at the entrance of the trimmer, with no operator input required. The system trims up to 1000 books of variable thickness and format size per hour and will accept a broad range of input sizes and deliver trimmed books from 5.7″ x 4.05″ up to 13.38″ x 11.69″. The heavy duty construction allows the trimmer to be run in a 24/7 production environment with consistent high quality finishing. A uniquely designed, automated trim removal system ensures consistent running without jamming. The system can also trim stacked books of the same untrimmed size and finished format at the same time, up to 2.55″ in height, for high productivity when variable trimming is not required. For same size production runs, the trimmer can be set up offline via the touch screen by inputting the desired untrimmed and finished size.
|Untrimmed Book Size||(Spine x Fore-edge) 5.825″ x 4.13″ to 13.78″ x 12.6″|
|Finished Book Size||(Spine x Fore-edge) 5.705″ x 4″ to 13.39″ x 11.815″|
|Trim Width||Fore-edge .04″ to 4.33″, Top and Bottom .04″ to 3.15″|
|Trim Height||.04″ to 2.56″|
|Production Speed||400 to 1,000 cycles/hour (higher production with piled books)|
|Voltage/Frequency||3-Phase 200 to 220 V, 50/60 Hz (compressed air required)|
|Machine Dimensions||79.8″ (W) x 126″ (D) x 63.9″ (H)|
