The Standard Horizon HT-80 Three-knife Trimmer is designed for operation in-line with the Standard Horizon BQ-470, SB-07, and SB-09S perfect binders, or for use off-line. The HT-80 includes advanced set-up automation through a user-friendly 10.4” color touch-screen control panel to meet the requirements of the short run print-on-demand book market. After inputting the untrimmed and finished trim book sizes, automated adjustments include the infeed, jogging, and knife sections. The HT-80 allows for trimming of variable thickness books, one after another, for true on demand book production. It can trim finished books from sizes ranging 5.5” x 3.9” up to 13.4” x 11.8”, with programmable memory for up to 200 different jobs, for instant recall of frequently-run jobs. Precision stepper motors accurately position all guides and clamps to insure professional quality cutting at speeds up to 1,000 cycles per hour. A uniquely designed servo-motor controlled jogging mechanism helps provide accurate book registration. The swing knife movement ensures sharp and accurate trims to produce a clean finished book, and a silicon spray unit is available to keep the knife clean during operation.
|Untrimmed Book Size||(Spine x Fore-edge) 5.71″ x 4.135″ to 13″ x 13″ (larger size possible with optional cutting module)|
|Finished Book Size||(Spine x Fore-edge) 5.475″ x 3.9″ to 11.81″ x 11.81″ (larger size possible with optional cutting module)|
|Trim Width||Top-bottom: up to 1.18″, Fore-edge: up to 1.18″|
|Trim Height||.04″ to 2″|
|Production Speed||400 to 1000 cycles/hour|
|Voltage/Frequency||3-Phase 200 to 220 V, 50/60 Hz (compressed air required)|
|Machine Dimensions||63.4″ (W) x 102.8″ (D) x 59.7″ (H)|
